Model: AB-17S
Spray Type: LVLP (Low Volume Low Pressure)
Feed Type: Suction Feed (Bottom Cup)
Material: Stainless Steel + Aluminum Cup
Nozzle Sizes: 1.3mm / 1.5mm / 1.8mm
Working Pressure: 2.0–3.5 bar
Air Consumption: 3.5–4.2 CFM
Spray Distance: 150–200mm
Viscosity Compatibility: Low to Medium
Spray Pattern Width: 180–230mm
Air Inlet: 1/4" BSP
Paint Cup Capacity: 1000ml
Cup Material: Stainless Steel
Adjustments: Fan, Fluid, Air controls
Finish: Smooth atomization with low overspray
Body Finish: Matte black with blue knobs
Weight: Approx. 800g
Nozzle Material: Stainless Steel
Needle Material: Stainless Steel
Coatings Supported: Water-based, Solvent-based, Primers, Clears
Atomization: High
Transfer Efficiency: ≥80%
Air Efficiency: Low air usage
Maintenance: Easy to clean and disassemble
Applications: Automotive, Woodwork, Metal, Machinery
Target Users: Auto Technicians, Industrial Painters
Packing: Blister/Box
Environment: Workshops, Body Shops, Paint Booths
Surface Treatment: Powder-coated or anodized
Connector Type: Threaded
Durability: High-pressure resistant design
Extras: Replaceable nozzle set
Spraying Speed: Fast, even output
Eco Feature: Less paint waste
Corrosion Resistance: Excellent
Sealing: Durable leak-proof seals
After-Sales: 1-year warranty, lifetime support
Certification: CE
